Victron Multiplus 24/500/10-16

Description

Victron MultiPlus 24/500/10-16: Multifunctional Inverter/Charger Combination

Discover the power and versatility of the Victron MultiPlus 24/500/10-16, an advanced pure sine wave inverter and battery charger in one compact enclosure. This device is perfect for both DIY campervan builders and boat owners looking for a reliable energy solution.

The Victron MultiPlus 24/500/10-16 combines a powerful pure sine wave inverter, an advanced battery charger with adaptive charging technology, and a super-fast AC transfer switch. These features make it a versatile device that meets the demands of modern off-grid energy solutions.

Installation:

• Use a 10mm² battery cable (not included) for connection.
• Install the MultiPlus in a well-ventilated area to prevent overheating.

Usage:

• With the Digital Multi Control panel, you can set the maximum generator or shore power.
• The MultiPlus takes into account other power consumers and uses the remaining power to charge the battery.

Add the Victron MultiPlus 24/500/10-16 to your cart today and experience the ultimate energy solution for your campervan or boat! Do you have any questions? Please contact us for more information.

Features

Key Benefits:

• Proven Reliability: The Victron MultiPlus is designed with technology that has been reliably working for years. This means the device is resistant to short circuits and overheating, making it safe and durable to use.
• PowerControl: This feature helps prevent your power source, such as a generator or shore power connection, from being overloaded. The MultiPlus ensures that other devices take priority for available power and only uses the remaining power to charge the battery.
• PowerAssist: PowerAssist ensures that your power source, such as a generator or shore power, can deliver more power when needed. During a peak in power consumption, the MultiPlus automatically supplements with power from the battery, and recharges it when consumption drops.
• High Start-up Power: The MultiPlus can easily handle devices with high start-up currents. This includes LED lamps, halogen lamps, or power tools that require a lot of power when switched on.
• Search Mode: This feature helps save energy. If there is no or low power consumption, the MultiPlus switches itself off and checks every two seconds if power is needed again. This reduces power consumption at no load by approximately 70%.

Specifications

• Input Voltage: 12VDC
• Output Voltage: 230VAC
• Output Power: 500VA / 430W
• Peak Power: 900W
• House Battery Charge Current: 10A
• Starter Battery Charge Current: 1A
• Recommended Battery Capacity: 50 - 100 Ah
• Protection Class: IP 21
• Dimensions (h x w x d): 311 x 182 x 100 mm
• Weight: 4.4 kg
